ARRIS Agricultural Seed Spraying Fertilizer Spraying Machine for Sprayer Drones

UF0048
Price:
    Please select the information you wantX
Quantity:
-
+
(99 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
  • Description
  • Reviews
The seed and fertilizer spreader is sepcially designed for agricultural spraying drones. It is suitable for seeds and fertilizers with the diameter less than 6mm. It is suitable for the agriculture drones with 39mm to 42mm diameter water tank outlet. The seeds and fertilzer spreader is made of soft material parts, which maximize the protection of all kinds of seeds during the spraying without being damaged by the smashing, which greatly improves the spraying efficiency.The impeller rotation speed and shutter opening (setting of the knob switch of the transmitter) can be set with the radio, and uniform spraying is possible without being covered with granules.



The spreader is designed with a flow door switch and a stepless adjustment of the speed of the disk. The speed of the disk and the door switch can be adjusted via the remote control.


Specifications:
Item name: ARRIS seeds and fertilier spreader
Operating voltage: 12-17V
Power consumption: 20 W
Scattering width: 2-5M
Distribution distance: 2-5M
Sprinkling speed: 2 L / MIN
Weight: 450G
Material: Carbon Fiber / TPU

Since the inner diameter of the entrance of the spreader is 40 MM, it can be installed on the outside diameter of the tank outlet is 40 MM (39 to 42 MM).

YRX410, YRX416, YRX616, YRX620 and E410, E416 of ARRIS YRX series can be installed and used.




How to Use:
After properly connecting the power supply (POWER), impeller rotation speed (SPEED), and shutter opening (SWITCH), turn on the LED switch before turning on the power. Please be careful because the operating voltage of the spreader is 12-17V, and since the power consumption is 20W, if the power consumption of the power supply is 20W or less, the power is insufficient, the shutter cannot be opened, and the impeller May also slow down.




Precautions for Use:

It is recommended to set all knob switches for the impeller rotation speed (SPEED) and shutter opening (SWITCH) control switches. Set the stroke of the impeller rotation speed (SPEED) channel to 1000US-2000US. In the case of datalink3 transmitter, the pump is operated by the combination of D button and LW dial.

Please check the shutter condition before starting work.
Confirmation method:
When the shutter opening switch is set to the lowest position, the shutter is in the fully closed state, if not closed, the channel is in the fully closed state (LED lights up to let you know). Please set the stroke of.
When the shutter opening switch is set to the maximum position, if the shutter is not fully open, set the channel stroke.
